| Series Designation | 415 Series |
| Type | Reducing Regulator |
| Special Features | Non-Vented |
| PSI Out | 0 to 5000 psi |
| Hand Loaded/Operated or Dome/Air Operated | Hand/Spring Loaded |
| Maximum Rated Pressure | 6000 psi |
| Outlet Pressure Range | 50-5000 psi |
| Outlet Pressure Rating | 6000 psi |
| Inlet Port Size | 2 ea 1/4 in. FNPT (One Gauge, One Inlet) |
| Outlet Port Size | 2 ea 1/4 in. FNPT (One Gauge, One Outlet) |
| Flow Coefficient (Cv) | 0.06 (equals 0.07 in. orifice) |
| Outlet Pressure Variations with Inlet Pressure Variations | 70 psi rise/1000 psi inlet drop |
| Leakage | Bubble Tight |
| Weight | 710 g |
| Overall Length | 5.5 Inch |
| Round Diameter | 2.25 Inch |
| Minimum Temperature | -15 ºF |
| Body Materials | Anodized Aluminum |
| Internal Materials | Anodized AluminumBrassStainless |
| Seal Materials | Kel-FViton |
| Repair Kit/Service Items | 839-5000-NV |
| Accessories | Mount Ring: P/N 657 |
